Fusebox and diagnostic socket locations Opel Zafira 2005 - 2009 | Haynes Manuals

Fusebox and diagnostic socket locations Opel Zafira 2005 - 2009 | Haynes Manuals

Regular checks /

October 2025

1 minute read

Time

5 minutes

Difficulty

Find your vehicle

- step 1

Fuses are located on the left-hand side of the luggage compartment

- step 2

Additional fuses are located on the left-hand side of the engine compartment
