Fusebox and diagnostic socket locations
Time
10 minutes
Difficulty
Find your vehicle
- step 1
Unclip the cover from the fusebox on the left-hand side of the engine compartment
- step 2
Rotate the fastener 90Â ° ...
- step 3
... and lower the GEM from beneath the glovebox to access the fuses
- step 4
Undo the fasteners and remove the luggage compartment left-hand side panel ...
- step 5
... to access additional fuses
